All in one Air Conditioning


A compact non-expensive all-in-one solution for applications where a outdoor unit is not possible or not preferred.  Easy to install

(3.2 kW / 11000 Btu) High & Low Wall Application heating and cooling


All in One air conditioning installation manual

View full selection here


all in one air conditioning unit for conservatories etc. Low or hgh wall application.


Products Key Features:


This "Through the wall unit" all in one air conditioning system and has NO outdoor unit. Finished in a attractive silver metal effect and featuring a compact Italian design. These units are new to the UK market and are a budget all in one solution where a outdoor unit is not possible or not preferred. The air is exchanged directly through two ducted air grilles at the back of the unit which takes air from outside to cool and expels the hot air through the other.


Ideal Applications:

These units are placed on an internal wall and do not need a professional installation as they are pre-gassed and no interconnecting pipe is needed. The unit can be placed at low level or on a dwarf wall, ideal for conservatories. Ideal applications are high rise premises, listed buildings, apartments and hotels.


Technical Information:

CoP 2.62
Quiet operation
Infra-red controller
slim construction
Timer Function
Self contained construction no outdoor unit
Heatpump and dehumidification
High and low wall mounting application
Power source 1 ph 240V
Type.  Fixed Speed
COOLING (nominal) max. kW 3.2
HEATING (nominal) max. kW 3.5
UK Cooling (max) kW n/a
UK Sensible Cooling kW n/a
E.E.R. n/a
Energy label in heating  C
Energy label in cooling  C
C.o.P  2.62
Dimensions mm-
550 x 930 x 260
Net Weight - 44 kg
Refrigerant - R410a
ECA - No



View Installation Manual Here

View Sales manual Here

Current Range of All In One Air Conditioning Units:


Compact All In One Air Conditioning Wall Unit With Electrical Heater 2.9 kW / 10000 Btu EH0533 240V~50hZ

Compact (All In One) air conditioning wall unit (2.9 kW / 10000 Btu) EH0532 240V~50hZ

Prem SW All In One Air Conditioning Heat Pump Floor / Wall 3.0 kW / 11000 Btu EH0554 240V~50hZ

Powrmatic Vision 2.3 All In One Packaged Air Conditioner And Heat Pump (2.3kW / 9000 Btu) 240V~50hZ
